| Package Speaker | Kanaler | 5.1 | |
|---|---|---|---|
| Högtalarsystem | Systemets frekvensrespons | 28 Hz–25 kHz | |
| Impedans | 6 ohms (without subwoofer) | ||
| Fronthögtalare | Typ | Full-range bass-reflex | |
| Element | 7 cm (2-3/4”) full-range cone | ||
| Nominell ingångseffekt | 30 W | ||
| Maximal ingångseffekt | 100 W | ||
| Känslighet | 83 dB / 2.83 V / 1 m | ||
| Storlek (B x H x D) | 112 x 176 x 116 mm; 4-3/8” x 6-7/8” x 4-5/8” | ||
| Vikt | 0.59 kg / unit; 1.3 lbs. / unit | ||
| Centerhögtalare | Typ | Full-range acoustic suspension | |
| Element | 7 cm (2-3/4”) full-range cone | ||
| Nominell ingångseffekt | 30 W | ||
| Maximal ingångseffekt | 100 W | ||
| Känslighet | 84 dB / 2.83 V / 1 m | ||
| Storlek (B x H x D) | 276 x 111 x 118 mm; 10-7/8” x 4-3/8” x 4-5/8” | ||
| Vikt | 0.73 kg; 1.61 lbs. | ||
| Surround Speaker | Typ | Full-range bass-reflex | |
| Element | 7 cm (2-3/4”) full-range cone | ||
| Nominell ingångseffekt | 30 W | ||
| Maximal ingångseffekt | 100 W | ||
| Känslighet | 83 dB / 2.83 V / 1 m | ||
| Storlek (B x H x D) | 112 x 176 x 116 mm; 4-3/8” x 6-7/8” x 4-5/8” | ||
| Vikt | 0.59 kg / unit; 1.3 lbs. / unit | ||
| Subwoofer | Typ | Advanced YST II | |
| Element | 20 cm (8”) cone | ||
| Uteffekt | 50 W (5 ohms, 100 Hz, 10% THD) | ||
| Dynamisk Effekt | 100 W (5 ohms) | ||
| Frequency Response | 28–200 Hz | ||
| Twisted Flare Port | Yes | ||
| Power Consumption | 40 W | ||
| Storlek (B x H x D) | 291 x 292 x 341 mm; 11-1/2” x 11-1/2” x 13-3/8” | ||
| Vikt | 8.5 kg; 18.7 lbs | ||
