Speaker General Bracket

General Bracket

BWS20-120

Wall Mounting brackets

  • Net weight: 0.6kg; 1.3lbs
  • Load capability: 7kg; 15.4lbs
  • Applicable for: VXS5, S55, S15, HS5I, MSP3A, MSP3, MS101III

BWS20-190

Wall Mounting brackets

  • Net weight: 0.85kg; 1.9lbs
  • Load capability: 7kg; 15.4lbs
  • Applicable for: VXS5, S55, S15, HS5I, MSP3A, MSP3, MS101III

BCS20-150 Utgången

Ceiling Bracket

  • Net weight: 0.9kg; 2lbs
  • Load capability: 10kg; 22.1lbs
  • Applicable for: VXS8, VXS5, S55, S15, HS5I, MSP5 STUDIO, MSP3A, MSP3, MS101III

BCS20-210 Utgången

Ceiling Bracket

  • Net weight: 1.0kg; 2.2lbs
  • Load capability: 10kg; 22.1lbs
  • Applicable for: VXS8, VXS5, S55, S15, HS5I, MSP5 STUDIO, MSP3A, MSP3, MS101III

BWS50-190

Wall Mounting Bracket

  • Net weight: 1.2kg; 2.6lbs
  • Load capability: 20kg; 44.1lbs
  • Applicable for: HS8I, HS7I, MSP7 STUDIO

BWS50-260

Wall Mounting Bracket

  • Net weight: 1.4kg; 3.1lbs
  • Load capability: 20kg; 44.1lbs
  • Applicable for: HS8I, HS7I, MSP7 STUDIO

BBS251

Baton Bracket

  • Net weight: 2.3kg; 5.1lbs
  • Load capability: 30kg; 66.2lbs
  • Applicable for: IF2208, IF2108, IF2205, CBR15, CBR12, CBR10, DBR15, DBR12, DBR10, C112VA, HS8I, HS7I

BWS251-300

Wall Mounting Bracket

  • Net weight: 4.4kg; 9.7lbs
  • Load capability: 30kg; 66.2lbs
  • Applicable for: IF2208, IF2108, IF2205, CBR15, CBR12, CBR10, DBR15, DBR12, DBR10, C112VA, HS8I, HS7I

BWS251-400

Wall Mounting Bracket

  • Net weight: 5.2kg; 11.5lbs
  • Load capability: 30kg; 66.2lbs
  • Applicable for: IF2208, IF2108, IF2205, CBR15, CBR12, CBR10, DBR15, DBR12, DBR10, C112VA, HS8I, HS7I

BCS251

Ceiling Bracket

  • Net weight: 2.3kg; 5.1lbs
  • Load capability: 30kg; 66.2lbs
  • Applicable for: IF2208, IF2108, IF2205, CBR15, CBR12, CBR10, DBR15, DBR12, DBR10, C112VA, HS8I, HS7I

BAS-10

Free-Angle Clamp

BMS-10A Mic Stand Adaptor

  • Net weight: 0.24kg; 0.5lbs / Load capability: 5kg; 11.0lbs
  • Applicable for: MG10XU, MG10, MG06X, MG06, AG06, AG03, EMX2, S15, MSP3A, MSP3, MS101III, STAGEPAS 600i, STAGEPAS 400i, STAGEPAS 600BT, STAGEPAS 400BT

For DZR/CZR Series

UB-DZR15V / UB-DZR15VW U-Brackets

U-brackets enabling simple and easy rigging in vertical configurations. (for DZR15/15-D, DZR15W/15-DW, CZR15, CZR15W)

  • Net weight: 5.9kg; 13.0lbs
  • Applicable for: DZR15/15-D, DZR15W/15-DW, CZR15, CZR15W
  • Black or white finish

UB-DZR15H / UB-DZR15HW U-Brackets

U-brackets enabling simple and easy rigging in horizontal configurations. (for DZR15/15-D, DZR15W/15-DW, CZR15, CZR15W)

  • Net weight: 6.2kg; 13.7lbs
  • Applicable for: DZR15/15-D, DZR15W/15-DW, CZR15, CZR15W
  • Black or white finish

UB-DZR12V / UB-DZR12VW U-Brackets

U-brackets enabling simple and easy rigging in vertical configurations. (for DZR12/12-D, DZR12W/12-DW, CZR12, CZR12W)

  • Net weight: 4.7kg; 10.4lbs
  • Applicable for: DZR12/12-D, DZR12W/12-DW, CZR12, CZR12W
  • Black or white finish

UB-DZR12H / UB-DZR12HW U-Brackets

U-brackets enabling simple and easy rigging in horizontal configurations. (for DZR12/12-D, DZR12W/12-DW, CZR12, CZR12W)

  • Net weight: 4.7kg; 10.4lbs
  • Applicable for: DZR12/12-D, DZR12W/12-DW, CZR12, CZR12W
  • Black or white finish

UB-DZR10V / UB-DZR10VW U-Brackets

U-brackets enabling simple and easy rigging in vertical configurations. (for DZR10/10-D, DZR10W/10-DW, CZR10, CZR10W)

  • Net weight: 3.6kg; 7.9lbs
  • Applicable for: DZR10/10-D, DZR10W/10-DW, CZR10, CZR10W
  • Black or white finish

UB-DZR10H / UB-DZR10HW U-Brackets

U-brackets enabling simple and easy rigging in horizontal configurations. (for DZR10/10-D, DZR10W/10-DW, CZR10, CZR10W)

  • Net weight: 3.8kg; 8.4lbs
  • Applicable for: DZR10/10-D, DZR10W/10-DW, CZR10, CZR10W
  • Black or white finish

For DXR Series

UB-DXR15 U-Brackets

U-brackets allow simple and easy rigging in both horizontal and vertical configurations.(for DXR15)

UB-DXR12 U-Brackets

U-brackets allow simple and easy rigging in both horizontal and vertical configurations.(for DXR12)

UB-DXR10 U-Brackets

U-brackets allow simple and easy rigging in both horizontal and vertical configurations.(for DXR10)

UB-DXR8 U-Brackets

U-brackets allow simple and easy rigging in both horizontal and vertical configurations.(for DXR8)

For Installation Series

HAF3-2112

Horizontal Array Frame fot 3 Speakers

  • Available for: IF2112(M)/95/64/99×3
  • Net weight: 9kg

HAF3-2115

Horizontal Array Frame fot 3 Speakers

  • Available for: IF2115(M)/95/64/99×3
  • Net weight: 10kg

HAF3-3115

Horizontal Array Frame fot 3 Speakers

  • Available for: IF3115/95/64×3, IH2000/95/64×3, IH2000/95/64×2 and IL1115×1, IH2000/95/64×1 and IL1115×2, IL1115×3
  • Net weight: 14kg

HAF3-S18

Horizontal Array Frame fot 3 Speakers

  • Available for: IF3115/95/64×2 and IS1218×1, IH2000/95/64×2 and IS1118×1
  • Net weight: 29kg

HAF2-2112

Horizontal Array Frame fot 2 Speakers

  • Available for: IF2112(M)/95/64/99×2
  • Net weight: 4kg

HAF2-2115

Horizontal Array Frame fot 2 Speakers

  • Available for: IF2115(M)/95/64/99×2
  • Net weight: 5kg

HAF2-3115

Horizontal Array Frame fot 2 Speakers

  • Available for: IF3115/95/64×1, IH2000/95/64×1 and IL1115×1
  • Net weight: 6kg

VAF2-2112

Vertical Array Frame fot 2 Speakers

  • Available for: IF2112(M)/95/64/99×2
  • Net weight: 4kg

VAF2-2115

Vertical Array Frame fot 2 Speakers

  • Available for: IF2115(M)/95/64/99×2
  • Net weight: 5kg

VAF2-3115

Vertical Array Frame fot 2 Speakers

  • Available for: IF3115/95/64×2, IH2000/95/64×2
  • Net weight: 6kg

UB2112

U-Brackets

  • Available for: IF2112(M)/95/64/99/AS
  • Net weight: 4kg
  • * The bracket for the UB series is designed to be used horizontally. It cannot be used vertically.

UB2115

U-Brackets

  • Available for: IF2115(M)/95/64/99/AS
  • Net weight: 9kg
  • * The bracket for the UB series is designed to be used horizontally. It cannot be used vertically.

UB2000

U-Brackets

  • Available for: IH2000/95/64, IL1115
  • Net weight: 9kg
  • * The bracket for the UB series is designed to be used horizontally. It cannot be used vertically.

UB2208

U-Brackets

  • Available for: IF2208
  • Net weight: 3kg
  • * The bracket for the UB series is designed to be used horizontally. It cannot be used vertically.

UB2108

U-Brackets

  • Available for: IF2108
  • Net weight: 2kg
  • * The bracket for the UB series is designed to be used horizontally. It cannot be used vertically.

UB2205

U-Brackets

  • Available for: IF2205
  • Net weight: 1kg
  • * The bracket for the UB series is designed to be used horizontally. It cannot be used vertically.
