STAGEPAS 100BTR mkII
Bärbart PA-system
-
Ny
Bärbart PA-system utrustat med en 100 W effektförstärkare, koaxial kompressionsdrivrutin med 1,4-tums röstspole HF och 6,5-tums kon LF, en 3-kanals mixer, internt litiumjonbatteri, ljud-I/O-funktionalitet via USB eller Bluetooth® och stöd för USB Power Delivery (USB PD).
- 100 W klass D-förstärkare
- 1,4 tum HF + 6,5 tum LF högkvalitativ koaxial kompressionsdrivrutin med FIR-filter för delningsfilter
- 3-kanals mixer (2 monofoniska mikrofon-/linjeingångar + 1 linjeingång)
- Utrustad med en 2-bands master-EQ
- Kompatibel med Hi-Z-ingång (endast kanal 2)
- Utrustad med mix-out
- Bärhandtaget fungerar även som ett justerbart stativ
- Kompatibel med ljudackompanjemang via Bluetooth
- Valfri bärväska (BAG-STP100) finns för bekväm transport
- Internt litiumjonbatteri
- Utrustad med ljud-I/O-funktionalitet via USB- eller Bluetooth®-anslutning
- Stöd för USB Power Delivery (USB PD)
STAGEPAS 100BTRPortable PA System
Portable PA system equipped with a 100 W power amp, coaxial compression driver with 1.4” voice coil HF and 6.5” cone LF, a 3-channel mixer, and internal lithium-ion battery
- 100 W Class-D amplifier
- 1.4” HF + 6.5” LF high-quality coaxial compression driver using an FIR filter for the crossover
- 3-channel mixer (2 monaural mic/line + 1 line)
- Equipped with a 2-band master EQ
- Compatible with Hi-Z input (Channel 2 only)
- Equipped with mix-out
- Carrying handle doubles as an adjustable stand
- Compatible with audio accompaniment over Bluetooth
- Optional carrying bag (BAG-STP100) available for convenient transport
- Internal lithium-ion battery
STAGEPAS 100Portable PA System
Portable PA system equipped with a 100 W power amp, coaxial compression driver with 1.4” voice coil HF and 6.5” cone LF, and a 3-channel mixer.
- 100 W Class-D amplifier
- 1.4” HF + 6.5” LF high-quality coaxial compression driver using an FIR filter for the crossover
- 3-channel mixer (2 monaural mic/line + 1 line)
- Equipped with a 2-band master EQ
- Compatible with Hi-Z input (Channel 2 only)
- Equipped with mix-out
- Carrying handle doubles as an adjustable stand
- Compatible with audio accompaniment over Bluetooth
- Optional carrying bag (BAG-STP100) available for convenient transport
Options
BAG-STP100Carrying Bag
Carrying bag for STAGEPAS 100.
- Weight: 1.1 kg (2.4 lbs)
- Dimensions (W x H x D): 370 x 240 x 240 mm (14.6" x 9.5" x 9.5")
Funktioner
ÖKA DITT OMFÅNG, UTÖKA DIN RÄCKVIDD
STAGEPAS 100 är ett bärbart PA-system som erbjuder en perfekt balans mellan hög ljudkvalitet och ultimat bärbarhet, vilket gör att du kan förvandla praktiskt taget vilken plats som helst till din egen intima livescen. Den lätta men tåliga designen, den enkla användningen och det fantastiska ljudet hos STAGEPAS 100, som finns i två versioner, en med batteri och en utan, hjälper dig att nå ut till din publik och uttrycka din prestation fullt ut.
Den batteridrivna STAGEPAS 100BTR mkII erbjuder även ljud-I/O-funktionalitet via USB- eller Bluetooth®-anslutning, så att du kan visa upp dina framträdanden med kristallklart ljud för publik på andra platser eller kommunicera med kollegor på avstånd.
Compact design. Big sound.
Far more than just a speaker that amplifies your mic or instrument inputs, the diminutive STAGEPAS 100 delivers impressive sonic performance by leveraging some of the same technologies used in our high-end professional products. A powerful, high-quality coaxial compression driver combined with Yamaha’s FIR-X filters for the HF and LF crossover deliver sound pressure, precise phase response, and a natural dispersion that will ensure every nuance of your performance is conveyed loud and clear to your audience.
Coaxial compression drivers utilize a common motor structure sharing a single magnet, reducing weight and bringing LF and HF closer together to provide a more ideal point sound source. Since sharing a magnet reduces magnetic flux, lowering the sound pressure, these drivers use voice coils made of a light aluminum material called "CCAW" wound in a square shape referred to as "Edgewound" to increase magnetic flux and ensure sufficient sound pressure, and also feature a device called a "demodulation ring" that suppresses magnetic flux disturbance to maintain a high level of sound quality. Additionally, they are equipped with an air venting structure in the basket to reduce LF wavering at high volumes, a polyimide diaphragm to balance HF durability with smooth high-frequency characteristics, and a short aluminum horn for better directional control, durability, and heat dissipation. These compact units house advanced, state-of-the-art technologies.
Start the show in seconds
With an unrivaled ease of operation and a setup requiring mere seconds, the STAGEPAS 100 will have you sounding great and performing in an instant. Just turn the power on, connect a micro-phone and your instrument, turn the volume up, and you're ready to go. The master EQ is right on the front panel making it easy to dial in your sound or adjust settings on the fly.
“A PA in the palm of your hand”
With all the essentials for a compact PA packed into a durable cabinet weighing just 5 kg, the STAGEPAS 100 takes portability to a whole new level. Having a personal live stage you can easily carry in one hand makes it possible to set up and play literally anywhere, anytime.
Stöd för hybridapplikationer
Den batteridrivna STAGEPAS 100BTR mkII erbjuder ljud-I/O-funktionalitet via USB- eller Bluetooth-anslutning, vilket gör det möjligt att skicka och ta emot röstsignaler till och från en dator eller smartphone. Den kan också användas för hybridapplikationer såsom streaming av liveframträdanden eller online-seminarier via mobila enheter som är anslutna till ett nätverk.
-
6 timmars non-stop-prestanda
STAGEPAS 100BTR mkII och STAGEPAS 100BTR är kompatibla med litiumjonbatterier med stor kapacitet som klarar upp till 6 timmars kontinuerlig drift, vilket ger tillförlitlig prestanda i miljöer där det inte finns någon strömkälla tillgänglig.
*STAGEPAS 100BTR mkII stöder USB PD (Power Delivery).
-
Multipoint Bluetooth® connectivity
The STAGEPAS 100 also comes equipped with multipoint supported Bluetooth functionality adding even more convenience to your set up and operation with wireless connection for music/ audio playback using smartphones and tablets.
-
The right direction
Easily control your coverage area with the carrying handle that doubles as a stand when the unit is placed on the floor. The attachment screws can be adjusted to change the angle of inclination to direct your sound exactly where it needs to go.
-
Mounting possibilities
The handle of the STAGEPAS 100 also features a 3/8" diameter screw hole that enable mounting on a microphone stand for more versatile sound dispersion options.
-
Whenever. Wherever.
The dedicated BAG-STP100 carrying bag features internal pockets for storing adapters, cables etc., as well as a padded shoulder strap for safe and easy transport to any location.
-
Kompatibla Hybridapplikationer
STAGEPAS 100BTR mkII kan skicka och ta emot ljudsignaler till och från en dator eller smartphone via USB eller Bluetooth®.
